Description
- High-concerned chemical: None
- Material: Aluminum alloy
- Type: Hand Tool Parts
- Origin: Mainland China
- place of origin: Guangdong, China
- brand name: GREE
- model number: GMC18QD-K3NNB2A
- capacity (btu): 9000-36000BTU
- cop: 3.62
- EER: 3.21
- power (w): 1640
- power type: DC
- after-sales service provided: Free spare parts, Onsite Installation
- warranty: 3 years
- type: Split Wall Mounted Air Conditioners
- cooling/heating: Cooling/Heating
- operating language: English
- application: Hotel, Outdoor, garage, Commercial, Household
- power source: Electric
- remote control: Yes
- maximum airflow rate: 850
- App-Controlled: Yes
- fixed frequency/variable frequency: Variable frequency
- private mold: Yes
- Logo/graphic design: Silk screen printing, hot stamping, uv printing
- packaging types: Corrugated Box
- Compressor type: Triple-cylinder Two-stage Rotary Compressor of Variable Volume Ratio
- Compressor name: GREE
- Applicable temperature range: -30℃~54℃
- WIFI Control: Yes
- Intelligent Defrosting: Yes
- Anti-corrosive Golden/Blue Fin: Yes
- High Temp Resistance PCB: Fireproof
- Refrigerant: R410A/R32
- Auto Clean: X-FAN
- Low Noise: 19dB
Hello, my friend. If you are interested in this product, you can place an order directly or add my WhatsApp:+86 19310099020. I am Amber, a sales specialist from China.
Product Description
Product Paramenters
|
MODEL
|
GMC09QB-K3NNB2A
|
GMC12QC-K3NNB2A
|
GMC18QD-K3NNB2A
|
GMC24QE-K3NNB2A
|
|
Function
|
Cooling
|
Cooling
|
Cooling
|
Cooling
|
|
Capacity-Cooling/BTU
|
9500
|
12000
|
18000
|
22000
|
|
EER
|
3.21
|
3.21
|
3.21
|
3.21
|
|
Energy Class
|
A
|
A
|
A
|
A
|
|
Power Supply
|
1PH,220-240V,50HZ
|
1PH,220-240V,50HZ
|
1PH,220-240V,50HZ
|
1PH,220-240V,50HZ
|
|
Power Input-Cooling/W
|
870
|
1095
|
1630
|
2010
|
|
Rated Current-Cooling/A
|
5.9
|
9
|
14
|
17
|
|
Airflow Volume-Indoor
|
530/490/430/330
|
650/560/480/300
|
900/850/750/600
|
1200/1000/800/650
|
|
|
|
|
|
|
|
Sound Pressure Level-Indoor
|
39/36/32/26
|
41/37/33/29
|
47/43/40/36
|
49/45/40/37
|
|
Outline Dimension-W*H*D/mm
|
790*275*200
|
845*289*209
|
970*300*224
|
1078*325*246
|
|
Package Dimension-W*H*D/mm
|
866*357*271
|
921*379*281
|
1041*383*320
|
1148*413*350
|
|
Net Weight/Gross Weight-Indoor/kg
|
9/11
|
10.5/12.5
|
13.5/16.5
|
17/20.5
|
|
Sound Pressure Level-Outdoor
|
51
|
52
|
53
|
55
|
|
Piping Connection-Gas/mm
|
φ9.52
|
φ12
|
φ12
|
φ16
|
|
Piping Connection-Liquid/mm
|
φ6
|
φ6
|
φ6
|
φ6
|
|
Outline Dimension
|
776*540*320
|
848*540*320
|
899*596*378
|
913*680*378
|
|
-W*H*D/mm
|
|
|
|
|
|
Package Dimension-W*H*D/mm
|
823*595*358
|
881*595*363
|
948*645*420
|
997*740*431
|
|
Net Weight/Gross Weight-Outdoor/kg
|
26.5/29
|
31.5/34
|
45/48
|
52/56
|
|
Loading Quantity-40’GP/sets
|
224
|
192
|
156
|
120
|
|
Loading Quantity-40’HQ/sets
|
262
|
240
|
179
|
140
|
